Specification
| No. |
Part |
|
Material |
| 1 |
Regulating Screw |
|
35# Steel |
| 2 |
Bush |
|
Polyformaldehyde (Black) |
| 3 |
Screw Nut |
|
35# Steel |
| 4 |
Nut Cap |
|
Reinforced Nylon |
| 5 |
Top Cover |
|
ST-13 Iron |
| 6 |
Spring |
|
65 Mn |
| 7 |
Screw Ⅱ |
|
Stainless Steel |
| 8 |
Sheeting |
|
ST-13 Iron |
| 9 |
Check Washer Ⅰ |
|
Stainless Steel |
| 10 |
O Ring Ⅰ |
|
NBR |
| 11 |
O Ring Ⅲ |
|
NBR |
| 12 |
Leather Packing |
|
Rubber |
| 13 |
Strainer |
|
Stainless Steel |
| 14 |
Washer |
|
H62 |
| 15 |
Spacer Ⅱ |
|
Stainless Steel |
| 16 |
Tie Rod |
|
HPb59-1 |
| 17 |
O Ring Ⅱ |
|
NBR |
| 18 |
Control Agent |
|
Polyformaldehyde (White) |
| 19 |
Cap |
|
HPb59-1 |
| 20 |
Jam |
|
Rubber |
| 21 |
Check Washer Ⅱ |
|
Polyformaldehyde (White) |
| 22 |
Screw Ⅰ |
|
Stainless Steel |
| 23 |
Spacer Ⅰ |
|
Stainless Steel |
| 24 |
Body |
|
Bronze C89833 |
| 25 |
Leather Spaser |
|
Rubber |
| 26 |
Union Nut |
|
Bronze C89833 |
| 27 |
Union Tube |
|
Bronze C89833 |
